Model Number: AK-119s Product features: 1 small product volume, high sensitivity, strong anti-interference ability; 2 RXB12 and four pin definitions, usage is the same. Price is slightly lower than RXB12 can...
Model Number: AK-119s
1 small product volume, high sensitivity, strong anti-interference ability;
2 RXB12 and four pin definitions, usage is the same. Price is slightly lower than RXB12 can be directly replaced.
Technical parameters:
The working voltage: DC3~5V
The transmission rate: 4.80KBPS
The static current: 6mA
The receiving sensitivity: -105dBm
- size: 30× 9× 5mm
The working temperature of ~+80 DEG C: -20
The frequency of 315MHZ/433.92MHZ (please note: place an order clear)
] applications: car alarm, security, machine learning, intelligent home, garage door, gate, lock, electric curtains, industrial control and so on.
The receiver structure for super heterodyne receiving wireless ook signal and received signal output COMS signal given external Decoder IC decoding.
We have AK119 and AK119S, the differences is pin. AK119S chip we have used 16pin module. And AK119 chip we used 8pin
