The module adopts a high-performance timing CPU design that runs fast. It has an LED power indicator and switch trigger timing LEDs. The output can be connected to AC 250V 10A...
The module adopts a high-performance timing CPU design that runs fast. It has an LED power indicator and switch trigger timing LEDs. The output can be connected to AC 250V 10A and DC 30V 10A, and the maximum control equipment is up to 2200W. It has a very high cost performance, good value for money. Can be used with other circuits to ensure time delay for other devices. Widely used with various electrical devices, especially for battery operated control products. Can also be used in the manufacture of hobby projects. Product features: Main chip: NE555. Operating voltage: 5/12 volts dc. Adjustable time: 0 to 10 seconds. Over temperature protection: turn off the output automatically after overtemperature. Module size: 68 mm x 21 mm. Module power and specifications: 1. Turn on the power relay and delay pulling. Specific: after the relay has supplied 12V current; relay absorb immediately and relay output status: normally open and generally disconnected, normally closed and public transmission; wait until the delay is 1-10s (adjustable), release the relay and current the state of the relay output: normally open and public transmission, normally closed and public inter; sol As long as the module is continuous, the condition remains power ed. Delay time adjustable, (0 ~ 10 seconds) 3. The increase of the potentiometer can extend the latency. 4. Increase the capacity C1 can increase latency. 5. The input power indicator has 6. With relay pull-out indicator 7. It can control AC 220V/10A devices. (Maximum controller 2000W) 8. Relays have free rotation protection. 9. Delay Time Formula: T=1.1RC For example: capacity 100uf resistance 100K T = 1.1 x 100000 x 0.0001 = 11 seconds
Operating voltage: DC 5 V / 12 V
Adjustable time: 0 to 10 seconds
Control voltage: AC 0 ~ 250 V
Max. Load capacity: 2200 W
